Purpose of the 30 mm Extension Profile
The 30 mm extension profile is designed to be installed onto the main PVC frame profile, increasing the overall frame depth by exactly 30 millimeters. This allows manufacturers and installers to:
- Adapt Cold Room Hinged Door frames to thicker wall panels
- Use a single main frame profile for multiple panel thicknesses
- Prevent gaps between the door frame and wall panels
- Achieve a clean, professional, and uniform appearance
The BOB-10092 plays a crucial role in modular door frame systems, particularly in cold room projects where wall panel thicknesses vary from one application to another.
Use in Cold Room Hinged Door Systems
Cold Room Hinged Doors require precise alignment between the door leaf, gasket, and frame. Any inconsistency in frame depth can cause uneven gasket compression, reduced sealing efficiency, and operational issues over time.
The BOB-10092 PVC Frame Profile is specifically engineered to be used in Cold Room Hinged Door frame systems, ensuring that the frame depth perfectly matches the wall panel thickness. This accurate depth adjustment allows:
- Proper gasket compression along the entire door perimeter
- Improved airtightness and thermal insulation
- Reduced risk of frost and condensation
- Longer service life for door components
Installation of the 30 mm extension profile is performed using a snap-fit (hammer-in) method, eliminating the need for welding. This installation approach significantly simplifies production and assembly processes while maintaining structural integrity.
Compatible PVC Frame Profiles
The BOB-10092 – 30 mm Extension Profile is fully compatible with Bob Modüler’s modular PVC frame system. It works seamlessly with the following PVC frame profiles used in Cold Room Hinged Door applications:
- BOB-10018 – PVC Frame Profile (main frame profile for Cold Room Hinged Doors)
- BOB-10094 – PVC Frame Profile (hinged door frame starting from 60 mm panel thickness)
- BOB-10147 – PVC Frame Profile (hinged door frame without heater cable channel)
- BOB-10024 – PVC Rear Cover / Rear Return Profile
- BOB-10019 – PVC Frame Profile (20 mm extension profile)
This wide compatibility allows manufacturers to combine different extension profiles and create multi-stage modular frame configurations tailored to specific project requirements.
Contribution to Modular Frame Systems
The BOB-10092 PVC Frame Profile is a key component in modular frame system architecture for Cold Room Hinged Door installations. Modular systems provide several operational and logistical advantages:
- Elimination of the need for multiple fixed-depth frame profiles
- Simplified stock management and reduced inventory complexity
- Faster production and assembly processes
- Lower risk of installation errors
- Flexible adaptation to varying wall panel thicknesses
By incorporating the 30 mm extension profile, modular frame systems become scalable, efficient, and cost-effective.
Advantages of PVC Material in Cold Room Frames
The BOB-10092 is manufactured from high-quality PVC, which is widely preferred in cold room door frame systems due to its technical advantages:
- Low thermal conductivity, minimizing thermal bridges
- High resistance to moisture and condensation
- Hygienic, smooth, and easy-to-clean surface
- Corrosion-free structure
- Long service life with minimal maintenance requirements
These properties make PVC frame profiles ideal for food storage, pharmaceutical cold rooms, and industrial cold storage facilities where hygiene and durability are essential.
Role in the Door Frame Production Process
During the production of Cold Room Hinged Door frames, the BOB-10092 PVC Frame Profile is used in the following steps:
- The main PVC frame profile is cut to size using 45-degree angle cuts
- The door frame structure is assembled
- Wall panel thickness is measured accurately
- The 30 mm extension profile is added using the snap-fit method
- If required, additional extension profiles are combined to achieve the desired depth
This systematic approach ensures precise dimensions, consistent quality, and reliable performance.
Areas of Application
The BOB-10092 PVC Frame Profile is widely used in:
- Cold Room Hinged Door frame systems
- Modular cold room door installations
- Industrial cold storage facilities
- Food processing and storage environments
- Logistics and distribution cold rooms
Technical Specifications
- Product Name: PVC Frame Profile
- Alternative Name: 30 mm Extension Profile
- Manufacturer: Bob Modüler
- Product Code: BOB-10092
- Material: PVC
- Extension Size: 30 mm
- Compatible PVC Frame Profiles:
- BOB-10018
- BOB-10094
- BOB-10147
- BOB-10024
- BOB-10019
- Door Type: Cold Room Hinged Door
- Installation Method: Snap-fit (hammer-in)
- System Type: Modular PVC frame system
Conclusion
The PVC Frame Profile (BOB-10092) is an essential component for precise depth adjustment in Cold Room Hinged Door frame systems. As a 30 mm extension profile, it delivers modular flexibility, easy installation, and perfect compatibility with different wall panel thicknesses. Its durable PVC construction ensures hygiene, thermal efficiency, and long-term performance in demanding cold storage environments. Manufactured by Bob Modüler, BOB-10092 is a reliable and professional solution for modern Cold Room Hinged Door installations.
