PVC Frame Profile – BOB-10024

PVC Frame Profile (Back Cover Profile)

The PVC Frame Profile (Back Cover Profile) is a complementary finishing component designed exclusively for cold room hinged door frame systems. Manufactured by Bob Modüler and supplied under the product code BOB-10024, this profile is used to close and protect the rear-facing surface of hinged door frames, ensuring a complete, hygienic, and professional installation.

Cold room hinged doors are widely used in cold storage facilities, food processing plants, pharmaceutical warehouses, and logistics centers. These doors require robust and precisely manufactured frame systems to guarantee correct door operation, airtight sealing, and long-term durability. During the installation of hinged door frames, once the main frame profile and extension profiles are assembled according to wall panel thickness, an exposed rear section remains on the wall-facing side of the frame. The PVC Frame Profile (Back Cover Profile) is specifically engineered to close this area.

Get a Quotation on WhatsApp Request a Quotation via Contact Form

Product Inquiry Form for PVC Frame Profile - BOB-10024

CAPTCHA image
SKU: BOB-10024 Category:

Purpose of the PVC Back Cover Profile

In cold room hinged door frame systems, modular PVC profiles are used to adapt the frame depth to different wall panel thicknesses. Without a dedicated back cover profile, the rear side of the frame would remain open, leading to both aesthetic and functional disadvantages.

The BOB-10024 PVC Frame Profile (Back Cover Profile) performs the following essential functions:

  • Fully covers the rear surface of the hinged door frame
  • Creates a clean and uniform transition between the door frame and the cold room wall panel
  • Prevents dust, moisture, and dirt accumulation behind the frame
  • Improves hygiene and ease of cleaning
  • Completes the door frame installation visually and structurally

For these reasons, the back cover profile is considered a mandatory finishing element in professional cold room hinged door frame systems.

Use in Cold Room Hinged Door Frame Systems

The BOB-10024 is designed only for cold room hinged door frames. Unlike sliding doors, hinged doors carry the full weight of the door leaf through the hinges mounted on the frame. This makes the frame structure and finishing details critically important.

By using the PVC Frame Profile (Back Cover Profile) in hinged door frames, installers achieve:

  • A fully enclosed and finished frame structure
  • Improved frame-to-wall panel integration
  • Higher hygiene standards in cold storage environments
  • A professional and durable final appearance

This profile is not suitable for sliding door systems and is exclusively dedicated to hinged door applications.

Role in the Modular PVC Hinged Door Frame System

Bob Modüler’s modular PVC hinged door frame system is designed to simplify production and installation while allowing compatibility with various wall panel thicknesses. The system consists of:

  1. Main PVC hinged door frame profile
  2. PVC extension profiles
  3. PVC Frame Profile (Back Cover Profile) – BOB-10024

Within this system, BOB-10024 closes the rear side of the frame after depth adjustment is completed. This ensures that the hinged door frame is mechanically complete, hygienic, and visually seamless.

Compatible PVC Frame Profiles

The PVC Frame Profile (Back Cover Profile) is fully compatible with the following PVC profiles used in cold room hinged door frame systems:

  • BOB-10018 – Main PVC frame profile for cold room hinged doors
  • BOB-10094 – Hinged door frame profile with 60 mm starting depth
  • BOB-10147 – Hinged door frame profile without heater cable channel
  • BOB-10019 – 20 mm PVC extension profile for hinged door frames
  • BOB-10092 – 30 mm PVC extension profile for hinged door frames

This compatibility allows BOB-10024 to be seamlessly integrated into all modular hinged door frame configurations.

Advantages of PVC Material

The BOB-10024 is manufactured from high-quality PVC material, which offers significant advantages in cold room hinged door frame applications:

  • Low thermal conductivity, preventing thermal bridges
  • High resistance to moisture and condensation
  • Hygienic and easy-to-clean surface
  • Corrosion-free and non-oxidizing structure
  • Long service life with minimal maintenance

These properties make PVC the preferred material for PVC frame profiles, cold room PVC profiles, and cold storage hinged door systems.

Installation and Production Process

During the production and installation of cold room hinged door frames, the PVC Frame Profile (Back Cover Profile) is applied as follows:

  1. The main hinged door frame profile is installed
  2. Required PVC extension profiles are added to match wall panel thickness
  3. The back cover profile is cut to the exact frame dimensions
  4. The profile is fixed to the extension profiles using a snap-fit (hammer-in) method
  5. The rear surface of the frame is fully closed, completing the installation

This method ensures fast, clean installation without welding or complex tooling.

Areas of Application

  • Cold room hinged door frames
  • Industrial cold storage facilities
  • Food processing and packaging plants
  • Pharmaceutical cold rooms
  • Logistics and distribution centers

Technical Specifications

  • Product Name: PVC Frame Profile (Back Cover Profile)
  • Manufacturer: Bob Modüler
  • Product Code: BOB-10024
  • Material: PVC
  • Application Area: Cold room hinged door frame systems
  • Compatible Profiles:
    • BOB-10018
    • BOB-10094
    • BOB-10147
    • BOB-10019
    • BOB-10092
  • Installation Method: Snap-fit (hammer-in)
  • System Type: Modular PVC hinged door frame system

Conclusion

The PVC Frame Profile (Back Cover Profile) – BOB-10024 is a critical finishing component used exclusively in cold room hinged door frame systems. By closing the rear-facing surface of the frame, it ensures hygiene, durability, and professional installation quality. Manufactured by Bob Modüler, BOB-10024 integrates seamlessly with modular hinged door frame systems and delivers reliable performance for modern cold storage projects.
