PVC Frame Profile
Definition as a Front Header Profile
A front header profile defines the main structural outline of a cold room door frame. Unlike profiles that include extensions or integrated channels, BOB-10133 features a clean and straightforward cross-section, without additional depth or resistance cable grooves.
This design approach provides several advantages:
- Establishes the core geometry of the door frame
- Eliminates unnecessary complexity in frame construction
- Enables faster and more reliable installation
- Reduces material and production costs
As a result, BOB-10133 is an ideal solution for projects that require efficient and economical hinged cold room door frames.
Application in Cold Room Hinged Door Frames
The BOB-10133 PVC Frame Profile is exclusively used in cold room hinged door frame systems. In hinged doors, all mechanical loads generated during opening and closing are transferred directly to the frame through the hinges. Therefore, frame integrity and dimensional accuracy are essential.
When used in hinged cold room doors, this profile ensures:
- Accurate positioning and alignment of the door leaf
- Stable hinge mounting points
- Uniform compression of door gaskets against the frame
- Reduced air leakage and improved insulation performance
Thanks to these characteristics, BOB-10133 contributes directly to the reliability and energy efficiency of cold storage installations.
Frame System Logic and Design Philosophy
The BOB-10133 PVC Frame Profile follows a simplified frame system logic similar to cost-optimized hinged door frame concepts. In this approach, the frame is designed to be:
- Structurally sufficient without unnecessary integrated features
- Adaptable to different wall panel thicknesses through complementary elements
- Easy to manufacture, transport, and assemble
Instead of relying on complex multi-channel profiles, the system prioritizes:
- A single primary front header profile
- Controlled depth adaptation through modular solutions
- Reduced part count and assembly steps
This frame logic offers significant benefits:
- Shorter production and installation times
- Lower risk of assembly errors
- Improved stock and inventory efficiency
- Overall cost reduction for cold room door projects
No Integrated Heating Cable Channel
One of the defining features of BOB-10133 is the absence of an integrated heating cable channel. This is a deliberate design decision.
In this system:
- The heating cable is not installed inside the door frame
- Anti-freeze protection is provided via the door leaf gasket
- The frame profile remains compact and structurally simple
This configuration offers multiple advantages:
- Easier maintenance and replacement of heating cables
- Reduced machining and processing on the frame profile
- Lower overall system cost
For projects where simplicity, serviceability, and economic efficiency are priorities, this solution is highly effective.
Advantages of PVC Material
The BOB-10133 PVC Frame Profile is manufactured from high-quality PVC material, which is particularly suitable for cold storage environments.
Key benefits of PVC in cold room door frames include:
- Low thermal conductivity, minimizing thermal bridges
- Excellent resistance to moisture and condensation
- Hygienic surface, easy to clean and maintain
- Corrosion-free performance
- Long service life with minimal maintenance requirements
These properties make PVC frame profiles an optimal choice for cold room door frames, cold storage facilities, and freezer door systems.
Manufacturing and Installation Process
During the production of a hinged cold room door frame, BOB-10133 is used as follows:
- The profile is cut according to door opening dimensions
- The main frame geometry is formed
- Frame depth is adapted to wall panel thickness using complementary solutions
- The frame assembly is completed and prepared for door installation
This process does not require welding and allows for fast, precise, and repeatable assembly.
Typical Application Areas
- Cold room hinged door frames
- Industrial cold storage facilities
- Food processing and storage plants
- Logistics and distribution centers
- Freezer and chiller room installations
Technical Specifications
- Product Name: PVC Frame Profile
- Alternative Name: Front Header Profile
- Manufacturer: Bob Modüler
- Product Code: BOB-10133
- Material: PVC
- Application: Cold room hinged door frames
- Heating Cable Channel: Not included
- Heating Cable Application: Door leaf gasket
- Design Concept: Simple and cost-effective frame system
Conclusion
The PVC Frame Profile (Front Header Profile) – BOB-10133 is a reliable and economical solution for cold room hinged door frame systems. Its resistance-channel-free design, simple geometry, and high-quality PVC construction make it ideal for projects seeking efficiency, durability, and ease of installation. Manufactured with Bob Modüler’s engineering expertise, BOB-10133 delivers consistent performance in demanding cold storage environments.
